Test principle: gas displacement method

Test functions: true density / absolute density, true volume, solid material and foam material porosity determination

Test efficiency: it takes about 3 minutes to complete a test, and the number of repeated tests can be set automatically

100cc (35cc &10cc), 10cc (3.5cc &1cc) sample pool can be configured flexibly

Test range: 0.0001 g / ml – no known upper limit

Resolution: 0.0001g/ml

Test accuracy: ± 0.02%

Repeatability: ± 0.02%

Test gas: helium or nitrogen

Sample types: solid samples of powder, granule, bulk, foam and so on.

Host specification: length 380mm * width 280mm * height 280mm, weight 10kg
